CARPATHATV700
A different choice within the Carpath range: 650.3 cc displacement and 321 mm ground clearance are listed on the 700 model sheet. Explore how its details fit your plans.
Get to know this CarpathTalk to our team
GALLERY01 / 03
FROM THE MODEL TO YOUR DAY
A good day begins with the right details.
Choose the place, then the route.
Plan a route where the vehicle is permitted and suitable for the conditions. The destination can be shared even if everyone arrives in their own way.
Bring what matters.
Compare the model dimensions, maximum load and listed rack limits with what you intend to bring and how you will transport it.
Make room for questions.
Confirm approved seating, passenger requirements and service options for your area before you set off.
CARPATH ATV700
The details behind the day.
Compare dimensions, equipment and loads with your plans. Our team can help you confirm the configuration for your market.
Powertrain
Engine typeSingle Cylinder,4-Stroke
Displacement (cc)650.3
Fuel systemEFI
Maximum power40.2kw/7000rpm
Maximum torque62N.m/5500rpm
CoolingLiquid Cooled
StartingElectric
TransmissionCVT,L-H-N-R
Chassis
SuspensionDouble A-Arm Independent
Suspension travel180mm/220mm
Front tyresSteel Wheel 26x9-12
Rear tyresSteel Wheel 26x11-12
Shock absorbersPreloaded, Oil Damped
Dimensions & equipment
Dimensions2377×1177×1410mm
Wheelbase1470mm
Ground clearance321mm
Winch3500LBS
Rack loadsF:30kgs/R:60kgs
Battery12V20AH
Fuel tank23L
Curb weight400kg
Maximum load250kg
